FP6000_image



FP6000 Series Options


Accessory Options

Cable/Adapter

Product Name Model No. Description
USB Cable (5 m) FP-US00

Cable used for touch panel data transmission between a host (USB Type A) and this product (USB Type B).

DP-DVI Cable (5m)

PFXYFPCBDPDV5M

 DP-DVI cable used to receive the image signal from host, passibetype (5m)
​*This is a passive cable. The host PC must support DP++ (Display Port Dual
mode).
DP-DVI Cable (3 m) PFXZPBCBDPDV32 DP-DVI cable used to receive the image signal from host, active type (3 m)
DVI Cable (5 m) FP-DV01-50 DVI-D cable used to receive the image signal from the host. DVI 1.0 compliant (DVI-D 24-pin plug) (5 m)

Adapters

Product Name Model No. Description
DP-DVI Adapter PFXZPBADCVDPDV2 DP-DVI Adapter can convert DP to DVI-D (socket), active type.
Panel cutout adapter for 12" Wide PFXZPAT6W1 Panel cutout adapter for mounting
for FP6000 Series
in a cutout of
PS-5600W (12" Wide)
Panel cutout adapter for 15" Wide PFXZPAT7W1 Panel cutout adapter for mounting
for FP6000 Series
in the cutout of
PS-5700W (15" Wide)
Panel cutout adapter for 19" Wide PFXZPAT8W1 Panel cutout adapter for mounting
for FP6000 Series
in a cutout of
PS-5800W (19" Wide)
Panel cutout adapter for 22" Wide PFXZPAT9W1 Panel cutout adapter for mounting
for FP6000 Series
in a cutout of
PS-5900W (22" Wide)

Screen sheets

Product Name Model No. Description
Anti-glare sheet for 10" Wide PFXZCAG5W1 Prevent reflections,
dirt-resistant sheet
(5 sheets/set)
Anti-glare sheet for 12" Wide PFXZCAG6W1
Anti-glare sheet for 15" Wide PFXZCAG7W1
Anti-glare sheet for 19" Wide  PFXZCAG8W1
Anti-glare sheet for 22" Wide PFXZCAG9W1
Screen protection sheet for 12" CA7-DFS12-01 Disposable,
dirt-resistant sheet
for the display
(5 sheets/set)
Screen protection sheet for 15"  CA3-DFS15-01

Others

Product Name Model No. Description
Enhanced front USB cover  *1 PFXZCDCVUS1 Front USB cover with fixing screw,
corresponding to IP66F, IP67F,
Type 1/4X Indoor use only /13
or ATEX certifications (5 pieces)

*1Supported by 12-inch and 15-inch models only.


Maintenance Options

Installation gaskets

Product Name Model No. Description
Installation gasket for 12" PFXZCDWG121 Provides dust and
moisture resistance
when this product is
installed into a solid; border-width: 1px; panel
(1 piece/set)
Installation gasket for 15" PFXZCDWG151
Installation gasket for 10" Wide PFXZCDWG102
Installation gasket for 12" Wide PFXZCDWG122
Installation gasket for 15" Wide PFXZCHWG154
Installation gasket for 19" Wide PFXZCWG8W1
Installation gasket for 22" Wide PFXZCWG9W1


Others

Product Name Model No. Description
Power connector (DC) CA7-ACCNL-01

Connector with fixable screws
to connect DC power supply cables
(Straight type, 5 pieces/set)
USB Clamp Type B  PFXYFPCLUSB Clamp to prevent disconnection
of USB cable
(USB Type B, 1 port, 5 clamps/set)
Installation fastener PFXZCAF1 Installation fastener
(4 pieces/set)
